Integrate a CDN resource with Invision Community Classic 4.x

Invision Community Classic 4.x can generate public file URLs through Orange's CDN by assigning a custom URL to each file-storage configuration. This setting applies to the file areas that use the updated configuration rather than every application resource.

Invision Community Cloud includes a managed global CDN and does not require this setup. The exact AdminCP labels in the current Classic release can differ from this verified 4.x workflow.

Administrator access to the self-hosted Invision Community installation, an active CDN resource, and an HTTPS-enabled custom domain are required. Back up the community files and database before changing storage settings.

  1. 1

    Prepare the CDN resource

    Configure the community hostname — community.example.com — as the CDN origin. Set the origin host header to the same hostname when the web server uses name-based virtual hosting.

    Activate cdn.example.com as the HTTPS custom domain and confirm that a known file path returns successfully through both the origin and CDN domains.

  2. 2

    Open the storage configurations

    Log in to the Invision Community AdminCP and navigate to System > Overview > Files > Storage Settings > Configurations. This AdminCP path matches the storage configurations workflow, including Use a custom URL.

  3. 3

    Select a supported storage configuration

    Edit the file-storage configuration used by the content that is delivered through the CDN. File System, FTP, and Amazon S3 configurations support a custom URL, while Database storage does not.

    When several configurations serve different file areas, update each required configuration separately.

  4. 4

    Set the custom URL

    Enable Use a custom URL and enter the full HTTPS CDN URL that maps to the same path as the storage configuration.

    For files stored under /uploads, enter:

    https://cdn.example.com/uploads

    Click Save.

  5. 5

    Check file-area assignments

    On Storage Settings, confirm that each required file area uses a configuration with the CDN custom URL.

    Changing the assigned storage configuration can start a background task that moves existing files. Wait for the task to finish because old and new URLs can coexist during the move.

  6. 6

    (Optional) Refresh cached file URLs

    If rendered pages still contain the origin domain, run the AdminCP support tool to clear the system cache, then clear any full-page or application cache in front of the community.

  7. 7

    Verify CDN delivery

    Open a community page that contains a file from the updated storage configuration and use the browser developer tools:

    1. Open the Network panel.

    2. Reload the page.

    3. Select an affected image, stylesheet, script, attachment, or theme file.

    4. Confirm that the request URL uses cdn.example.com and returns a successful response.

Integration troubleshooting

When files fail to load from the CDN domain, the cause is usually a storage assignment, a path mismatch, an origin error, or a cache that still serves the previous URL.

  • If only some files use the CDN domain, identify their file areas under Storage Settings and update the associated configurations.
  • For a 403 response, request the same file directly at the origin. Check file permissions, origin access rules, and the Host header.
  • If the browser reports mixed-content blocking, load the file over the HTTPS custom URL.
  • For a 404 response, compare the custom URL path with the original storage URL and the CDN origin path.
  • For a 502 response, verify the origin pull protocol and host header in the CDN resource.
  • If pages retain old URLs after clearing the cache, wait for any active storage move or background queue to finish.
